Home » AL9LC (220V1) 2-Post Lift - 9,000 Lb. Cap. - Floorplate - 220V 1Ph | 5176250
;
GrandPrix

AL9LC (220V1) 2-Post Lift - 9,000 Lb. Cap. - Floorplate - 220V 1Ph | 5176250

Only 1 left
P/N: 5176250
GrandPrix GP-9LC Two Post Car Lift
GrandPrix GP-9LC Two Post Car Lift
$4,660.10

⦿  30 days returns. Buyer pays for return shipping. See details

AL9LC (220V1) 2-Post Lift / 9,000 Lb. Cap. / Floorplate, 220V 1Ph

The APEX AL9LC is a 9,000-lb floorplate two-post lift engineered for shops and serious garages that need professional lifting capability in low-ceiling environments. Featuring dual symmetric and asymmetric arm configurations, long-reach telescoping arms, and a rugged chain-over lifting system, the AL9LC delivers stable, confident performance for a wide range of vehicles. Previously sold under the GrandPrix brand, the AL9LC now carries the APEX name while retaining the same proven design, performance, and BendPak-backed support.

  • 9,000-lb Lifting Capacity
    Handles passenger vehicles, performance cars, and light trucks with confidence.

  • Floorplate Two-Post Design
    Ideal for low-ceiling garages while maintaining full lifting capability.

  • Symmetric and Asymmetric Arm Configurations
    Allows flexible arm positioning for faster vehicle setup.

  • Triple-Telescoping Front Arms and Extended Rear Arms
    Provides exceptional reach for a wide range of wheelbases.

  • Automatic Safety Locks Every 3 Inches
    Ensures secure load holding throughout the lift range.

  • Automatic Arm Restraints
    Prevent unintended arm movement during service.

  • Heavy-Duty 6" x 6" Tubular Steel Carriage
    Delivers long-term structural strength and durability.

  • Chain-Over Lifting System
    Industrial-grade leaf chain engineered for reliable, low-maintenance operation.

  • Oversized Base Plates
    Improve stability and evenly distribute vehicle weight.

  • 36-Month Limited Warranty
    Industry-leading coverage backed by BendPak support.

Specifications:

  • Lifting Capacity: 9,000 lbs. (4,082 kg)

  • Max. Capacity / Front Axle: 4,500 lbs. (2,045 kg)

  • Max. Capacity / Rear Axle: 4,500 lbs. (2,045 kg)

  • Height Overall (A): 109.5" (2,781 mm)

  • Width Overall at Baseplate (B): 137.25" (3,486 mm)

  • Width Outside of Columns (C): 127.5" (3,238 mm)

  • Floor to Drive over Height (D): 1.25" (30 mm)

  • Width Inside Columns (E): 113.5" (2,880 mm)

  • Front Arm Reach (Min.) (F): 22.5" (571 mm)

  • Front Arm Reach (Max.) (F): 43.25" (1,099 mm)

  • Rear Arm Reach (Min.) (G): 33.5" (845 mm)

  • Rear Arm Reach (Max.) (G): 53.25" (1,353 mm)

  • Minimum Pad Height (H): 3.9" (100 mm)

  • Rise (I): 70" (1,778 mm)

  • Maximum Lift Height (Pad + 63mm Adapter) (J): 76.5" – 78.5" (1,943 – 1,994 mm)

  • Drive-Thru Clearance (K): 103" (2,618 mm)

  • Screw Pad Adjustment: 2" (51 mm)

  • Motor: 220 VAC / 60Hz / 1 Ph

  • Time of Full Rise: 65 seconds

  • Maximum Load Per Arm: 2,250 lbs. (1,023 kg)

  • Shipping Weight: 1,385 lbs. (630 kg)

Brand:GrandPrix
WH Rack:XYZ
