BendPak HDS-14LSX Alignment Lift

The BendPak HDS-14LSX Alignment Lift delivers a massive 14,000 lbs. lifting capacity, engineered for professional automotive shops that demand durability, precision, and efficiency. Built with advanced safety systems, heavy-duty aircraft cables, and integrated alignment technology, this lift ensures years of dependable performance for cars, trucks, and low ground-clearance vehicles. Its free-floating alignment design, dual-hub sheaves, and flow restrictor safety system make it a premium choice for high-volume operations. With optional rolling bridge jacks and extended-length frames, the HDS-14LSX offers unmatched versatility for wheel alignment, brake service, and general repair.

• Lifting Capacity: 14,000 lbs.

• Model: BendPak HDS-14LSX Alignment Lift

• Certified: CE Approved; meets EN 1493 European Standard

• Turn Plates & Slip Plates: Heavy-duty galvanized plates for precise alignment

• Dual-Hub Cable Sheaves: 10.5” diameter sheaves with 2.25” axles for long-term reliability

• Aircraft-Quality Lifting Cables: 1/2" stainless-steel cables for superior strength

• Adjustable Locking Positions: Multiple height positions for convenient operation

• Flow Restrictor System: Ensures safe, even descent in case of hydraulic failure

• Spring-Loaded Safety Locks: Auto-engage at each height for added safety

• Pneumatic Lock Release: Simple push-button system for smooth lowering

• Secondary Lock System: Detects cable slack and halts operation for protection

• Integrated Design: Enclosed cables, sheaves, and airlines for cleaner setup

• Power System: Electric-hydraulic system with ergonomic operator controls

• Runways: Adjustable for various tread widths; durable matte finish

• Ramps: Extended approach ramps for low-clearance vehicles

• Protective Conduit: Flexible rubber housing safeguards hoses and airlines

• Bridge Jacks (Optional): 7,000 lbs. capacity (Model RJ7W) for wheel and brake service

• Automatic Leveling System: Maintains balanced lift positioning

• Anti-Sway Slider Blocks: Internal system enhances stability

• Rugged Roller Axles: 1-3/8” heavy-duty axles and oversize sheaves for longevity

• Available Versions: Standard or extended frame (HDS14LSXE) for longer vehicles

• Ideal For: Wheel alignment, suspension work, brake service, and general repairs

Specifications:

• Lifting Capacity: 14,000 lbs. (6,350 kg)

• Maximum Capacity (Front Axle): 7,000 lbs. (3,175 kg)

• Maximum Capacity (Rear Axle): 7,000 lbs. (3,175 kg)

• Minimum Runway Height: 7.5" (191 mm)

• Maximum Rise: 70" (1,778 mm)

• Maximum Lifting Height: 77.5" (1,969 mm)

• Time to Full Rise: 60 seconds

• Overall Width: 130" (3,302 mm)

• Outside Length: 213" (5,410 mm)

• Overall Length: 242" (6,147 mm)

• Height of Columns: 92" (2,337 mm)

• Width Between Columns: 120" (3,048 mm)

• Drive-Thru Clearance: 98" (2,489 mm)

• Runway Width: 20" (508 mm)

• Length of Runways: 197.5" (5,017 mm)

• Width Between Runways: 34.5" (876 mm) or 41.5" (1,054 mm)

• Minimum 4-Wheel Alignment: 89" (2,261 mm)

• Maximum 4-Wheel Alignment: 156" (3,962 mm)

• Maximum 2-Wheel Alignment: 182" (4,623 mm)

• Minimum Wheelbase (Rated Capacity): 140" (3,556 mm)

• Minimum Wheelbase (75% Capacity): 120" (3,048 mm)

• Minimum Wheelbase (50% Capacity): 100" (2,540 mm)

• Minimum Wheelbase (25% Capacity): 80" (2,032 mm)

• Locking Positions: 15

• Lock Spacing: 4"

• Motor Power: 220 VAC / 60 Hz / 1 Ph

• Noise Level: 45 dB

• Shipping Weight: 3,216 lbs. (1,458 kg)

• Shipping Dimensions: 209" × 25" × 33" (5,308 mm × 635 mm × 838 mm)

A $395 surcharge from the freight carrier will be applied if no forklift or loading dock is available at the delivery location.
