BendPak P-9000LTF Low-Rise Scissor Car Lift

Only 1 left
P/N: 5175155
BendPak P-9000LTF Low-Rise Scissor Car Lift
BendPak P-9000LTF Low-Rise Scissor Car Lift
$7,239.75

⦿  30 days returns. Buyer pays for return shipping. See details

BendPak P-9000LTF Low-Rise Scissor Car Lift

The BendPak P-9000LTF is a 9,000-lb. lift designed for maximum lifting power with a zero footprint. It is the perfect solution for high-stance trucks, SUVs, and other heavy-duty vehicles. With the optional arm extension kit and truck adapter set, this lift can easily handle any frame, making it ideal for a variety of shop needs. Its low-profile, flush-mount design allows for easy storage and mobility in tight spaces, while its rugged steel channel frame and durable rubber lift blocks ensure years of reliable service.

Key Features:

  • Lifting Capacity: 9,000 lbs.

  • Low-Profile Design: Virtually disappears when flush-mounted, saving space in the shop.

  • Pneumatic Lock Release: Air cylinders provide maintenance-free, safe operation with easy release.

  • Rugged Steel Channel Frame: Heavy-duty construction with a power-coated steel frame for durability.

  • Solid Rubber Lift Blocks: Tough, durable rubber blocks for added lifting capacity and vehicle protection.

  • Optional Arm Set: Provides offset lifting and additional height for trucks and long-wheelbase vehicles.

  • Detachable Ramps: Easily convert the lift for different vehicle types with detachable ramps.

  • Dual-Pump Power Unit: Features a built-in proportioning valve for smooth operation.

  • Electronic Push-Button Controls: Easy, single-hand operation for efficient use.

  • Safety Features: Multi-position safety locks with air release for secure, remote operation.

  • Enhanced Adjustable Lifting Arms: For added flexibility in lifting different vehicles.

  • Powder-Coat Finish: Provides long-lasting protection against wear and tear.

Specifications:

  • Lifting Capacity: 9,000 lbs.

  • Lifting Height: Standard height plus optional block extension.

  • Construction: Rugged steel channel frame with a 10-step power-coating process.

  • Power Unit: 1.5 HP electric-hydraulic with dual pumps and proportioning valve.

  • Height When Lowered: Low-profile design for minimal space usage.

  • Safety Mechanism: Pneumatic lock release, automatic multi-position safety locks.

  • Platform Length: Reinforced to handle inboard loading.

  • Flush-Mount Option: Converts to a recessed drive-over lift when needed.

  • Lifting Capacity: 9,000 lbs. (4,082 kg)

  • Lifting Height: 24” (610 mm)

  • Lifting Height + Block: 27” (686 mm)

  • Overall Lift Platform Length: 58.5” (1,484 mm)

  • Overall Lift Platform Width: 24” (610 mm)

  • Overall Length: 74.4” (1,890 mm)

  • Lowered Height: 4” (102 mm)

  • Speed of Rise: 55 seconds

  • Standard Motor: 1.5 HP / 208-230 VAC / 60 Hz / 1 Ph

  • Shipping Weight: 1,134 lbs. (514 kg)

  • Shipping Dimensions: 77” x 40” x 24” (1,943 mm x 1,016 mm x 609 mm)

Items Included:

  • P-9000LTF Pit Lift

  • Instruction Manual

  • Safety Stickers and Labels

  • Rubber Lift Blocks

A $395 surcharge from the freight carrier will be applied if no forklift or loading dock is available at the delivery location.
